3005 H24 High Impact Pre Painted Aluminium With PVDF Paint For Patio Cover

Product Details

Place of Origin: China

Brand Name: Dingang

Certification: SGS,ITS,BV

Model Number: Prepainted Aluminium Coil

Payment & Shipping Terms

Minimum Order Quantity: 1000 Kgs / 1 Metric Ton

Price: Negotiable

Packaging Details: Seaworthy Packing With Wooden Pallet

Delivery Time: Within 35 Days After Order Confirmed And Down Paymetn Received

Payment Terms: T/T,L/C

Supply Ability: 5000 Tons / Per Month

Get Best Price

3005 H24 Pre Painted Aluminium


PVDF Paint Pre Painted Aluminium


Patio Cover Prepainted Aluminium Coil

3005 H24 High Impact Pre Painted Aluminium With PVDF Paint For Patio Cover

3005 H24 High Impact Pre-painted Aluminium with PVDF Paint for Patio Cover


Food Grade Roller Coating Aluminum Sheet Used For Bottle Metal Cap Product Characterics:

Alloy: 8011,5182,5052 and etc

Temper Grade: H14,H19

Material Thickness: 0.22-0.50mm

Material Width: 800-1500m

MOQ: Not Less Than 2000 kgs

Seaworthy Packing With Wooden Pallet

Auxiliary Material For Production: Detergents (Henkel,Germany) Food Grade Epoxy Resin Paints (PPG,Valspar or ICI)


*Remarks of Pre painted aluminum coil: Specific requirement of alloy, temper or specification can be discussed at your request


Use Appication: Bottle Metal Cap, Aluminum Pull Ring, Metal Lug Closure,Can Packing Box and so on


3005 H24 High Impact Pre Painted Aluminium With PVDF Paint For Patio Cover 0


Roller Coating Aluminum Coil Paint's Performance:


Test Item Paint
PVDF PE And Others
With Varnish Without Varnish
Paint Film Thickness, μ ≥22 ≥30 ≥18
Shine Tolerance Shine≥80 Unit, ±10 Unit Allowed
Shine≥20-80 Unit, ±7 Unit Allowed
Shine<20 Unit, ±5 Unit Allowed
Pencil Hardness ≥1H
Abrasion Resistance, L/μm ≥5 --
T-bend ≤2T ≤3T
Impact Strength 50KG.CM Without Depainting And Crack
Adhesive Force (Class) ≥1
Boiling Water Resistance Unvarying
Chemical Resistance Acid Endurance Unvarying
Alkali Stability Unvarying
Oil Resistivity Unvarying
Resistance To Solvent ≥70 ≥50
Scrub Resistance ≥10000 Times Unvarying
Dirt Resistance ≤15% --
Salt Spray Resistance(class) ≥ 2 class --


Advantages of Color Coated Aluminum Coil Used For Bottle Metal Cap


Color coated aluminum coils offer several advantages that make them a popular choice for various applications. Some of the key advantages include:

1.Aesthetic Appeal: Color coated aluminum coils are available in a wide range of vibrant and attractive colors. This makes them an ideal choice for architectural and decorative purposes, as they can enhance the visual appeal of buildings and structures.

2.Corrosion Resistance: Aluminum has a natural resistance to corrosion, and when coated with high-quality paint systems, its corrosion resistance is further enhanced. This makes color coated aluminum coils suitable for outdoor applications where exposure to harsh weather conditions is common.

3.Durability: The combination of aluminum's inherent strength and the protective coating's durability results in a long-lasting material that can withstand various environmental stresses without deteriorating quickly.

4.Lightweight: Aluminum is a lightweight material, making color coated aluminum coils suitable for applications where weight is a concern. This is particularly beneficial in industries such as aerospace and transportation, where reducing overall weight is essential for fuel efficiency and performance.

5.Flexibility and Formability: Color coated aluminum coils can be easily shaped, bent, and formed into different profiles and designs without compromising the integrity of the coating. This versatility allows for creative and innovative designs in architecture and product manufacturing.

6.Ease of Maintenance: The painted surface of color coated aluminum coils is relatively easy to clean and maintain. Regular cleaning with mild detergents and water can help preserve the appearance and performance of the material over time.

7.Environmentally Friendly: Aluminum is a recyclable material, and the coatings used on color coated aluminum coils can also be formulated to be environmentally friendly. This makes color coated aluminum a sustainable choice for various applications.

8.Thermal Reflectivity: Aluminum has excellent thermal reflectivity properties. Color coated aluminum coils with reflective coatings can help in reducing heat absorption, which is beneficial for energy efficiency in buildings, especially in warmer climates.

9.Customization: Color coated aluminum coils can be tailored to specific color requirements, enabling manufacturers and designers to match or create unique color schemes for their projects.

10.UV Resistance: High-quality coatings applied to color coated aluminum provide UV resistance, preventing colors from fading or degrading when exposed to sunlight for extended periods.

11.Cost-Effective: While initial costs might be higher compared to some other materials, the long-term benefits, including reduced maintenance and durability, can make color coated aluminum coils a cost-effective choice over the product's lifespan.

12.Wide Range of Applications: Color coated aluminum coils find applications in a variety of industries, including construction, automotive, electronics, signage, appliances, and more, due to their versatility, aesthetics, and performance characteristics.
